Safety and Reliable Industrial Biomass Fired Thermal Oil Boiler

Safety and Reliable Industrial Biomass Fired Thermal Oil Boiler

FOB Price:

US 2000-20000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

30 Set/Sets per Month

Port:

Tianjin, shanghai, qingdao, dalian, guangzhou

Place of Origin:

Hebei, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal

Brand:

Bangzi boiler

Products Model:

YLW

Products Details
Company Profile

Quick Details

Brand Name: Bangzi boiler

Model Number: YLW

Place of Origin: Hebei, China (Mainland)

Packaging & Delivery

Packaging Details: standard exportation package
Delivery Detail: Shipped in 30 days after payment

Specifications

Safety and Reliable Industrial Biomass Fired Thermal Oil Boiler

Product Description

Safety and Reliable Industrial Biomass Fired Thermal Oil Boiler

Coal or biomass fuel thermal oil boiler is a new type of heating equipment, with coal, oil, gas, biomass as fuel and flue gas as heat source, heat conduction oil (such as L - QB, L - QC, L - QD, etc.) as the heat carrier, through the circulating pump to force heat transfer medium to circulate in liquid phrase, and transfer heat to heat user equipment, then return to the heating furnace for re heating high temperature, low pressure, energy-saving equipment. Heating temperature can be as high as 340 ℃, and generally under working pressure of 0.8MPa, because of working in liquid state, safe and reliable.

Features:

1. Strong adaptability of different fuels
2. Diversity of grate structure.
3. Cubic tube combustion chamber.
4. Best coil design.
5. The optimal process design
6. Sufficient output.
7. Perfect automatic control measures
8. Leading technology in automatic control.

Technical parameters

projects	units	YLW-700	YLW-1000	YLW-1200	YLW-1400	YLW-2000	YLW-2400	YLW-2900	YLW-3500	YLW-4700	YLW-6000	YLW-7000	YLW-10000	YLW-18000
rated thermal power	kw	700	1000	1200	1400	2000	2400	2900	3500	4700	6000	7000	10000	18000
rated working pressure	MPa	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8
highest working temperature	℃	320	320	320	320	320	320	320	320	320	320	320	320	320
oil volumn in the boiler	cube meters	0.52	0.66	0.85	1.09	1.33	1.6	2.2	2.6	3.8	4.7	5.24	6.3	12.3
cycle oil volumn	cube meters/h	60	60	80	100	160	160	180	200	300	360	400	400	1000
pipe diameter	DN	100	125	125	125	150	150	150	200	200	250	250	300	350
applicable fuel	Coal, biomass, biomass pellets, pellets, wood chips, wood pellets, wood, sawdust, solid fuel...
thermal efficiency	%	more than 76%					more than 78%				more than 79%			more than 80%
coal consumption	kg/h	145	180	220	265	390	465	560	650	890	1120	1380	2200	3320

Accessories

production courses

Boiler installation drawing:
