3A/16A/30A Household Usage and Temperature Controller Theory touch room thermostat

 LCD touch screen controller for room thermostat

Used to control the fan coil, electric valve, air valve and other equipment, refrigeration / heating, in order to maintain the indoor temperature.

Applicable: Plumbing / heating / temperature control electric heating film

CE Certificated

Technical parameters

 Technical parameters

Heating Thermostat with weekly programming adopts the latest single-chip computer control technology.

1.It has the high reliability and powerful anti-jamming. It can realization energy-saving and comfortable living environment

2.The application is the electric heating equipment and Water heating system of electric heating or actuator control. According to the preset temperature, the thermostat will automatically start and stop the controlled object (valve, floor heating, the heating wall, electric heater etc).

3.Multiple time modes: 5+2/6+1/7days, the heating equipment supports different temperature setting accordingly with 6 time-modes daily. Users are free to choose manual mode or full automatic mode for different purposes.

4.Using flame resistance material, the heating equipment is safe and reliable. Its appearance is stylish and its mirror screen would be very easy to clean.

5.The clock would continue to run even if power was cut off and it will not affect the period setting value.

l Keypad lock function can prevent misuse of children.

About Packing

50 sets per carton with paper box ,carton size:51x36x22 cm;

40 sets per carton for blister packing, carton size : 48x35x29 cm;

100 pieces per carton for only thermostatic head, cartons size: 40x30x30 cm;

60 pieces per carton for only thermostatic valve body, carton size: 41x25.5x26 cm;

About 20000 sets /20” container with blister packing;

About 25000 sets/20” container with carton box;

Pallet packing is available.

About Guarantee:

2 Years guarantee counted from the days arrived in your warehouse.

Specifications

Size:DN10(3/8"), DN15(1/2"),DN20(3/4''),DN25(1'') Angle valve ,Straight valve, 3 way valve, H valve

Used Connection Pipe:

PPR/PB/PE pipe,Red copper pipe,pex-al-pex pipe,Matel pipe

OEM condition

Logo for the thermostatic head, the MOQ is 3000 pieces.

Logo for the thermostatic valve body, the MOQ is 10000 pieces.

Payment terms:

30%TT as deposit payment,70%TT against the Copy of B/L

L/C is available.

Delivery terms:

FOB NINGBO or FOB SHANGHAI can be choosed.

The production time is 25 days normally.
