F&C F3C-08EN02 Series M8, 3-wires NPN/PNP Proximity Sensor, Short Housing Type, Non-Flush Proximity Sensor

F&C F3C-08EN02 Series M8, 3-wires NPN/PNP Proximity Sensor, Short Housing Type, Non-Flush Proximity Sensor

Price:

US 5-10 / Piece

Min.Order Quantity:

20 Piece/Pieces

Supply Ability:

20000 Piece/Pieces per Month

Port:

Shenzhen, Guangzhou

Place of Origin:

Hunan, China (Mainland)

Payment Terms:

T/T,Western Union

Brand:

F&C

Products Model:

F3C-08EN02-N/P

Products Details
Company Profile

Quick Details

Brand Name: F&C

Model Number: F3C-08EN02-N/P

Place of Origin: Hunan, China (Mainland)

Packaging & Delivery

Packaging Details: 148*162mm packing plastic bag, sensor * 1, 2* screws
Delivery Detail: 15 working days

Specifications

Product Description

F3C series Proximity sensor
1) 2M soft PUR cable;
2) 360 degrees LED view;
3) With red protective tube for protecting cable;
4) Support for customizing, 5V DC offered.

Discriptions	Part Numbers	Output	Sensing Range	Detected Object	Cable
M8/Flush/Short Housing	F3C-08EN02-N R2M	NPN.NO	2mm	8×8×1(iron)	φ4×2M/3-wires
	F3C-08EN02-N2 R2M	NPN.NC
	F3C-08EN02-P R2M	PNP.NO
	F3C-08EN02-P2 R2M	PNP.NC

Response frequency	1000Hz/800Hz
Hysteresis	10%≤sensing distance
Operating voltage	DC:12~24VDC±10%/ can customize 5V
Current consumption	DC:≤8mA No—Load
Load current	DC:24V 150mA Max
Leakage current	DC:≤0.01mA no-Load
Residual votage	DC:≤1.5VDC No-load
Operating temperature	-20°C~+70°C
Material	PBTand SUS304
Wiring method	2M/3-wires
Protection degree	IP67

Diagram

F&C Electronics established a new company in changsha of Hunan province for produce in 2013, we specialized in making sensors. such as: fiber optical sensors, fiber amplifiers, photoelectric sensors, proximity sensors, laser sensors, color sensors etc.
Our current sensors have been widely used in industrial machinery and equipment, light industry, shoemaking industry, textiles, chemical, petroleum, tobacco, food industry, metallurgy,electric power field, for the purpose of limiting, position detection, automatic counting, speed measuring, automatic protection, signal transmission, protection, or isolation.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
