Concealed Wall Mounted Fan Coil Unit for Chilled Water System

1. Products Description of Concealed Fan Coil Units, Duct Fan Coil, Fan Coil Units

a. Fan Coil Units Introduction

The FP series chilled water fan coil units are designed specially to meet the varied requirements of zone cooling or heating using chilled water or hot water. Fan coil can be applied to 2 pipes 2, 3 rows or 4 rows systems to satisfy the requirements of a wide variety of air conditioning cooling or heating application. The FP series is available in concealed versions for ceiling installation. This unit is presented as a single block including: fan deck, cooling or heating coil, removable filter, drip tray, electrical connection box.

b. Concealed/ Duct Type Fan Coil Units Features:

FRAME AND STRUCTURE

Panels and frame are made of galvanized steel, properly punched and punched for fixing both accessories and the unit itself.

COOLING OR HEATING COIL

The coils are made of seamless tubes expanded into aluminum fins in continuous block. The connections have brass headers with female fittings and provided with easily accessible vent and drainage valve.

FAN DECK

The fan decks are composed of double suction centrifugal fans with aluminum impellers and 3-speed fan motors. Each fan motor assembly is dynamically balanced.

DRIP TRAY

The drip trays are made from sheet metal treated with polyester powder coating to ensure total resistance to atmospheric agents.

FILTER

The easily removable filter is made of filtering honeycomb polypropylene fabric and supported by an aluminum frame.

The filter is installed on the units with plenum only.

ELECTRICAL CONNECTION BOX

All electric wires are connected to enclosed electrical terminal block, situated on the same side of the water connections.

OPTIONAL

-3 speed switch

-ON-BOARD THERMOSTART

Mechanical type for two pipe system exposed version use, working mode selection (OFF-Heating-Cooling), ventilation (HIGH-MED-LOW) and room temperature setting.

c. Concealed Fan Coil Model Specifications:

Concealed Fan Coil Models Size Details:

2. Packaging & Shipping of Cassette Ceiling Type Fan Coil Units

Packages: Cartons, International Standard Package.

Cartons Packages as follows photos:

Shipping: Loaded Container in Our Factory and leave China from Qingdao Port:

3. Fan Coil Products Our Service

Quality First, we have the responsibility to provide the best quality and best service to all of the customers.

Also provide 24 hours technical support on the installation and usage.

4. Fan Coil Production

5. Finished Product
