Brand Name: OKM1000
Model Number: OKM
Place of Origin: Shandong, China (Mainland)
Modular step-in cold rooms for fruit
World famous compressor to support your project, BITZER!!, Germany brand, first level! competitive price supported from ONLYKEM!
One question, how to verify the Bitzer compressor original or not, ONLYKEM tell you:
Of course we also can supply other famous one, depends on your request! tell us, please!
Your advantage:
1. Over 10 years manufacturing experience, products sell well in many countries, full experience support to give you most suitable system
2. Compressor, we use all new origin famous brand, Bitzer, Copeland, Tecumseh, Maneruop or brand you appointed. other accessories are same,
3. Professional engineer support, can assist you from design to after sale service, choose us, it is beginning of your new sucess!!
Our modular walk in cold storage series is an integrated family of sandwich panels designed for quick cold room assembly. The panel configuration has been reduced to a minimum, so the overall effect is to offer the clients maximum design possibilities for cold rooms with a minimum amount of panels required on the site. All products from the modular range can be easily assembled without the need for special tools.
Specification for Cold storage room
| Dimension | Length x width x height customized |
| Panel | Polyurethane foam insulation panel,38~42kg/m3, fire resistance |
| Thickness of panel | 75mm,100mm, 120mm,150mm,180mm,200mm optional |
| Surface steel | color steel or stainless steel option |
| Panel Connection | cam lock connection |
| Door type | sliding door, hinged door option, size can be customized |
| Cold room temperature | -35~+15'C |
| Refrigeration unit | Bitzer Tecumseh, Copeland compressor for options |
| refrigerant | R134a, R404a, R507c |
| voltage | 380V/3ph/50~60hz, 230V/3PH/50~60HZ. |
| application | Seafood, meat quick freezing, and fruit and vegetable fresh keeping |
1. Polyurethane foam panel advantage and specification:
| Thickness(mm) | Temperature application(°C) | Weight(kg/m²) | R-value(m².k/w) |
| 50 | Above -5'C | 12.8 | 2.28 |
| 75 | above-15'C | 13.8 | 3.42 |
| 100 | above-15'C | 14.8 | 4.55 |
| 120 | above-15'C | 15.7 | 5.6 |
| 150 | above-15'C | 16.8 | 6.82 |
| 200 | above-15'C | 18.8 | 9.12 |
Tolerance Control
| Length(mm) | Tolerance(mm) | Straightness | ||
| Length | Width | Thickness | ||
| 500~3600 | ±3 | 0~3 | ±1 | 1/500 |
| 3600~6000 | ±4 | 0~3 | ||
| 6000~12000 | ±6 | 0~3 | ||
Our cold storage Polyurethane foam panel advantage:
1. reliable raw material, use galvanized steel cam lock, best color steel.
Reliable raw material specification.
2. Cold room storage door
sliding door and hinged door, 100mm and 150mm for option, special heater for low temperature application.
Safety: Emergency device keep your all stuff safety!!
3. Refrigeration modular walk in cold storage for shrimp, chiller storage for lobster system
The more details, contact with us, please.
