[TEKAIBIN] Silver TZ36D z-wave home automation Dual smart switch

[TEKAIBIN] Silver TZ36D z-wave home automation Dual smart switch

FOB Price:
US 25-40 / Piece
Min.Order Quantity:
64 Piece/Pieces
Supply Ability:
10000 Piece/Pieces per Month
Port:
Shanghai/Ningbo
Place of Origin:
Zhejiang, China (Mainland)
Payment Terms:
T/T,Western Union,Paypal
Brand:
TEKAIBIN
Products Model:
TZ36D
Share:
  • Products Details
  • Company Profile

Quick Details

  • Brand Name: TEKAIBIN

    Model Number: TZ36D

    Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

  • Packaging Details: 1 Box, size: 9*9.6*5.8cm, 64 PCS/CTN 1 Carton size: 40*38*25cm, GW: 10.2kg
  • Delivery Detail: 15-20 days after receive your payment.

Specifications

Product Description



  • MODEL NO. TZ36D, Z-WAVE Dual Wall Switch (3 wire)
  • The TEKAIBIN  Z-Wave dual wall switch is switching attached loads and is controlled either by the local switching paddle or remotely via the Z-Wave wireless protocol
  • It is included and controlled in a Z-Wave network by a remote control, a wireless control centre or any other kind of Z-Wave controller including a PC-software.
  • Beside the local switch the unit can control other Z-Wave units remotely in up to three additional Z-Wave groups, which are associated with this device. Tipping one time or two times the switching paddle performs the control. The left paddle controls the local load while the right paddle remotely controls Z-Wave associated devices only. The association of further Z-Wave devices needs to be done by a Z-Wave controller. The unit is powered by 230V power and needs a pattress box with 230 V power wires for installation. The unit is shipped completely with electronics, switching paddle and mounting frame in white style. It is designed for use within a 3-wire system, which means that a neutral wire is needed for operations.

Wall Switch  Selection Table



Model Voltage Max Load Frequency Range Color Controllable Z-Wave Groups

TZ36D

230VAC/50HZ 1380W 868.42MHZ(EU) / 869MHZ(RU) white, silver, golden 4
TZ36S 230VAC/50HZ 1380W 868.42MHZ(EU) / 869MHZ(RU) white, silver, golden 2

TZ66D vs TZ65D

Model

Controllable

 Z-Wave Groups

Function Max Load Voltage Appearance lighting
TZ36D 4 ON/OFF Switch 1380W 230VAC/50HZ same Capable of controlling fluorescent lighting
TZ35D 4 Dimmer Switch 300W 230VAC/50HZ same For use only with hard-wired incandescent lighting





Company Information



Our Services



Certifications



why YOUDO

YOUDO takes over a decade to offer you good quality products and best service !



Z-Wave Knowledge

Z-Wave makes any home a “smart home” – quickly, easily and affordably!
Z-Wave is a next-generation wireless ecosystem that lets all your home electronics talk to each other, and to you, via remote control. It uses simple, reliable, low-power radio waves that easily travel through walls, floors and cabinets. Z-Wave control can be added to almost any electronic device in your house, even devices that you wouldn't ordinarily think of as "intelligent," such as appliances, window shades, thermostats and home lighting.
Z-Wave unifies all your home electronics into an integrated wireless network, with no complicated programming and no new cables to run. Any Z-Wave enabled device can be effortlessly added to this network, and many non-Z-Wave devices can be made compatible by simply plugging them into a Z-Wave accessory module. In seconds, your device gets joined to the network and can communicate wirelessly with other Z-Wave modules and controllers.
And Z-Wave lets you control these devices in ways that give you complete command even when you're not at home yourself. You can control your Z-Wave household remotely from a PC and the Internet from anywhere in the world...even through your cell phone!
Z-Wave Is Simple – Z-Wave control is easily added to almost any device in minutes. Simply plug the device you want to control into a Z-Wave module, and "join" it to your Z-Wave network!
Z-Wave Is Modular – With Z-Wave, you can add as much or as little home control as you want over time. You can add Z-Wave to a device, a room, a floor or the entire home, according to your needs and desires.
Z-Wave Is Affordable – Unlike costly whole-home control systems that need special wiring and professional installation, Z-Wave is accessible and easy for the do-it-yourselfer.
Z-Wave Is Powerful – Z-Wave's intelligent mesh networking 'understands" the present status of any enabled device, and gives you confirmation that your devices have received the automatic or manual control commands you want.
Z-Wave Is Versatile – Z-Wave can be added to almost anything in your home that uses electricity, and gives you the power to control or monitor them from your home or away from home.
Z-Wave Is Intelligent – Z-Wave enabled devices can work together as a team. Have your garage door turn on your house lights when you come home. Have your door locks notify you when your children arrive home from school. Turn your downstairs lights off from upstairs. Create your own intelligent control "scenes" with Z-Wave!
Z-Wave delivers on all the promises of the wired home, and opens up exciting new possibilities for the home of the future. And that future is here now, because hundreds of Z-Wave enabled products are already widely available, from some of the best-known brands that you already know and trust. Take a few moments to browse through this site and better acquaint yourself with Z-Wave. Get to know how Z-Wave makes your home -- and your life -- safer, more secure, more economical, more convenient and more enjoyable!
