zhongshan shangfang instrument electronics SF-104P

FOB Price:

US 1-100 / Piece

Min.Order Quantity:

50 Piece/Pieces

Supply Ability:

200000 Piece/Pieces per Month

Port:

zhongshan

Place of Origin:

Guangdong, China (Mainland)

Payment Terms:

L/C,T/T,Western Union

Brand:

shangfang

Products Model:

SF-104P

Products Details
Company Profile

Quick Details

Brand Name: shangfang

Model Number: SF-104P

Place of Origin: Guangdong, China (Mainland)

Packaging & Delivery

Packaging Details: standard export package
Delivery Detail: 15 business days

Specifications

We have 15 years experience producing temperature controller.Our products are well-known for their stable performance and durability.

Besides conventional products,customized are offered as well. So,don' be hesitate to contact us,we will serve you with 100% enthusiasm

Satisfactory after-service is offered.Our technical team support you for any technical problem about products.And there is one year warranty for each one.

We ready to serve you. Let's build a win-win partnership!

Main products

Picture of factory

refrigeration thermostat temperature controller

Feature

1.Temperature control/Evaporator fan control
2.Automatic/manual defrost by electric heater
3.Time/temp. seting to end defrost
4. °C / °F degrees
5.Re-start delay

Technical Data

1.power supply:230V

2.Range of temperature : -45~45°C(-40~120°F)
Accuracy:±1°C (±2°F)
3.Compressor: N.O. 30A/250VAC
Defrost: N.O. 30A/250VAC
Evap. Fan: N.O. 30A/250VAC

Size

Dimension:77(Length)×35(Width)×30(Depth)mm
Mounting hole dimension:71(Length)×29(Width)mm

Circuit diagram

Parameter

Parameter	Function	Set range	Default
E1	Lower setpoint limit	-45°C/-45°F~Set temp.	-22°C/-8°F
E2	Higher setpoint limit	Set temp.~45°C/120°F	20°C/68°F
E3	Temp.Hysteresis	1~10°C/1~18°F	4°C/7°F
E4	Comp.start delay time	0~10Min	03Min
E5	Offset on room temp.	-20~20°C/-20~20°F	0
E6	Offset on evap.temp.	-20~20°C/-20~20°F	0
C1	Temperature unit	°C=Celsius °F=Fahrenheit	°C
F1	Max.defrost duration	1~60Min	20Min
F2	Defrost interval time	0~24Hr	04Hr
F3	Defrost termination temp.	0~20°C/32~68°F	8°C/46°F
F4	Display during defrost	0=Normal display 1=Last value before defrost	0
F5	Fan operating function	0=Parallel with comp. 1=Continuous running except defrost	0

Photos of item

Certificates

Established in 1998, started from customizing digital temperature controllers for freezer manufacturers, according to the idea of Credit standing roots quality, quality creates brand, and after years endeavor, Zhongshan Shangfang Instrument Meter Co., Ltd developed and produced a whole series of digital temperature&humidity controllers which widely used in refrigeration, air conditioning, heating, food and packaging machinery etc.

Shangfang controllers have the characters of compact design, easy operation, strongly anti-jamming and stable performance etc. The controllers are UL ,CE, CQC and RoHS approved.
