LPG Cylinder Valve - Gas Cylinder Valve LPG Cylinder Valve - Gas Cylinder Valve LPG Cylinder Valve - Gas Cylinder Valve LPG Cylinder Valve - Gas Cylinder Valve

LPG Cylinder Valve - Gas Cylinder Valve

FOB Price:
USD 2 / Piece
Min.Order Quantity:
2000 Twenty-Foot Container
Supply Ability:
5000000 Piece per Year
Port:
ningbo
Place of Origin:
China
Payment Terms:
L/C, T/T
Brand:
MINGSHI
Products Model:
LPG Cylinder Valve
Share:
  • Products Details
  • Company Profile

Quick Details

  • Brand Name: MINGSHI

    Model Number: LPG Cylinder Valve

    Place of Origin: China

Packaging & Delivery

  • Packaging Details: box
  • Delivery Detail: 30-45 days

Specifications

LPG Cylinder Valve Series

MINGSHI "YSF/YSQ/YJF" Series LPG Cylinder Valves are suitable for switching gas flow on the cylinders whose operating medium is Liquefied Petrolcum Gas (LPG) with operating presure ≤2.5MPa and environmental temperature of -40ºC to 60ºC


LPG Cylinder Valve - Gas Cylinder Valve







Product Type YSQ-1
Gas Service Liquefied Petroleum Gas
Working Pressure 2.5MPa
Orifice Diameter ≥ø7mm
Body Material Brass
Inlet Thread PZ27.8/W28.8/25E
Outlet Thread M22*1.5LH
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 345











Product Type YSQ-1A
Gas Service Liquefied Petroleum Gas
Working Pressure 2.5MPa
Orifice Diameter ≥ø5mm
Body Material Brass
Inlet Thread PZ19.2/W19.8/17E
Outlet Thread M22*1.5LH
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 255









Product Type YSQ-1B
Gas Service Liquefied Petroleum Gas
Working Pressure 2.5MPa
Orifice Diameter ≥ø7mm
Body Material Brass
Inlet Thread ZM26*2
Outlet Thread W20-14LH
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 205









Product Type YSQ-3
Gas Service Liquefied Petroleum Gas
Working Pressure 2.5MPa
Orifice Diameter ≥ø7mm
Body Material Brass
Inlet Thread PZ27.8/W28.8/25E
Outlet Thread M22*1.5LH
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 340









Product Type YSQ-3A
Gas Service Liquefied Petroleum Gas
Working Pressure 2.5MPa
Orifice Diameter ≥ø5mm
Body Material Brass
Inlet Thread PZ19.2/W19.8/17E
Outlet Thread M22*1.5LH
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 250









Product Type YSQ-4
Gas Service Liquefied Petroleum Gas
Working Pressure 1.7MPa
Orifice Diameter ≥ø7mm
Body Material Brass
Inlet Thread 3/4 -14NGT
Outlet Thread CGA510
Pressure of Safety Device 2.86~3.12MPa(5m3/min)
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 360









Product Type YSQ-6
Gas Service Liquefied Petroleum Gas
Working Pressure 1.7MPa
Orifice Diameter ≥ø7mm
Body Material Brass
Inlet Thread 3/4 -14NGT
Outlet Thread CGA510
Pressure of Safety Device(Big Flow) 2.86~3.12MPa (10m3/min)
Surface Treatment Shot Blasting or Pickling
Working Temperature -40ºC~+60ºC
Design Weight (g/pcs) 370
