Brand Name: NPT
Model Number: 1000GFT
Place of Origin: Shandong, China (Mainland)
Technical Parameter for 1MW Natural Gas Generator
Model |
1000GFT |
|
Structure |
integral |
|
Exciting method |
AVR Brushless |
|
Rated Power (kW) |
1000 |
|
Rated Current(A) |
1804 |
|
Rated Voltage(V) |
400/230 |
|
Rated Frequency(Hz) |
50 |
|
Rated Power Factor |
0.8 LAG |
|
Gas Engine |
Model |
NY792D105TL |
Type |
V type, 4 stroke, electric control ignition, pre-mixed lean burn, turbocharged after cooled |
|
Cylinder number |
12 |
|
Bore x Stroke (mm) |
200x210 |
|
Total displacement (L) |
79.2 |
|
Rated Power (kW) |
1050 |
|
Rated Speed (r/min) |
1500 |
|
Fuel Type |
natural gas |
|
Control panel |
NPT Brand |
LCD display |
Control module |
HGM9320 or 9510 |
|
Operation language |
English |
|
Alternator |
Model |
XN6G |
Brand |
MBH( Germany) |
|
Shaft |
Single bearing |
|
Rated Power (kW) |
1000 |
|
Enclosure protection |
IP23 |
|
Efficiency (%) |
95.2% |
|
Standard Configuration for 1MW Natural Gas Generator
1. New gas engine
2. Radiator 40°C max,fans are driven by belt,with safety guard
3. 24V charge alternator
4. New Alternator(Stamford or Marathon),single bearing, IP22-23, insulation class H,brushless
5. Steel frame base, shock absorber
6. Gas pressure regulator,air and gas mixer
7. Electronic speed governor and actuator
8. Back-fire relief valve
9. Dry type air filter, oil filter
10.Main line circuit breaker
11.Digital automatic control panel
12.Emergency stop button
13.Two 12V batteries,rack and cable
14.Ripple flex exhaust pipe,exhaust siphon, flange, muffler
15.Spare parts and tools, User manual etc.
16.Controler:smartgen,woodward etc
Optional Equipment for 1MW Natural Gas Generator
1.Oil heater system
2.ATS(Automatic Transfer Switch)
3.Soundproof canopy
4.Parallel system
5.Grid-connection system
6.CHP/Cogeneration system
7.Emergency cooling system
8.Automatic oil filling system
9.Heat recovery
10. Remote control and monitoring system
Advantage for 1MW Natural Gas Generator
Reliable Quality
Rich Experience, advanced technology and good selection on all parts etc. have made our gas generator sets to be more reliable and durable.
Longer Life
Good quality and regular maintenance will make our gas generator sets to keep a longer life. Usually the life will be about 5-10 years for small power; about 10-15 years for large power.
Competitive Price
We would try our best to offer every customer a reasonable and competitive price based on equality and mutual benefit.
Best Service
We have deeply known the importance of pre-sale service, after-sale service etc. for a long-term development and would be responsible for every product we sell.
High return rate of investment
Most suitable customized design and solution, more competitive price, lower fuel consumption, lower maintenance cost and longer life etc. will make you to earn a high return rate of investment.
NPT Feature Service for 1MW Natural Gas Generator
Pre-sale service
Provide specification parameter and consultants service, customized design optional.
According the requirement of customer we can design and offer a complete set of equipment,
such as mute device and heat treatment device and so on.
After –sale service
Installation guide and maintenance manual
Guide user to install the machine and free debugging machine for free.
Training the operator for the user, cooperate with the user finish the acceptance work.
Tracking service
Regularly consult feedback from end user ,avoid potential problem and solve problem in time.
