Brand Name: PengNan
Model Number: HP-127060
Place of Origin: Fujian, China (Mainland)
CE Certification High Performance 12706 for cooler
Model No. | Imax(A) | TH=27℃ | N | Dimensions(mm) | |||||
Qmax(W) |
VMax(V) | ΔT Max | A | B | C | D | |||
C-TES1-127030 | 3 | 26 | 15.4 | 58 | 127 | 30 | 30 | 30 | 3.6 |
C-TES1-127040 | 4 | 33 | 15.4 | 58 | 127 | 30 | 30 | 30 | 3.2 |
C-TEC1-127040 | 4 | 36 | 15.4 | 58 | 127 | 40 | 40 | 40 | 3.9 |
C-TEC1-127050 | 5 | 44 | 15.4 | 58 | 127 | 40 | 40 | 40 | 3.6 |
C-TEC1-127060 | 6 | 51 | 15.4 | 58 | 127 | 40 | 40 | 40 | 3.6 |
TES1-127020 | 2 | 18.1 | 15.4 | 67 | 127 | 25 | 25 | 25 | 3.6 |
TES1-127025 | 2.5 | 21.4 | 15.4 | 67 | 127 | 30 | 30 | 30 | 4 |
TES1-127030 | 3 | 25.7 | 15.4 | 67 | 127 | 30 | 30 | 30 | 3.6 |
TES1-127040 | 4 | 33.4 | 15.4 | 67 | 127 | 30 | 30 | 30 | 3.2 |
TEC1-127060 | 6 | 51.4 | 15.4 | 67 | 127 | 40 | 40 | 40 | 3.6 |
TEC1-127040 | 4 | 33.4 | 15.4 | 67 | 127 | 40 | 40 | 40 | 3.9 |
HP-127040 | 4 | 43.1 | 15.4 | 67 | 127 | 40 | 40 | 40 | 4.6 |
HP-127080 | 8 | 77 | 15.4 | 67 | 127 | 40 | 40 | 40 | 3.3 |
HP-161080 | 8 | 94.5 | 20 | 67 | 161 | 40 | 40 | 40 | 3.3 |
HP-199080 | 8 | 116.8 | 22.6 | 67 | 199 | 40 | 40 | 40 | 3.3 |
HP-127120 | 2 | 118 | 15.4 | 67 | 127 | 40 | 40 | 40 | 3.45 |
HP-031080 | 8 | 17.9 | 3.52 | 67 | 31 | 20 | 20 | 20 | 3.54 |
HP-127060 | 6 | 55 | 15.4 | 67 | 127 | 40 | 40 | 40 | 3.91 |
(1)All products are RoHS and REACH compliant, SGS ISO9001 verified.
(2)Peltier module material are UL certification
(3)Standard Wire is 150mm
(4)Peltier module moisture protection standard is sealed by white RTV silicone, but also support select other moisture protection style, Such as translucent silicone, black epoxy.
(5)Peltier module flatness tolerance support select 0.3, 0.2mm, 0.13mm, 0.1mm.
