MJ PDF05 10 12mm diameter 220V 24V 12V Can be adjusted Normally Closed Outlet magnetic valve

Product Show

Product description and advantage:

Solenoid valve used in the automatic control system, automatic solar water, infrared ray induction sanitary ware, showers, water machine, water control machine, automatic water machine, water boiler, the campus one-card equipment switch control, such as the inlet and outlet port at 180 ° Angle, says the pass-through Hun or linear valve!

Because of the variety type and size, before buying, please make sure which type you need in our store , due to time is limited so do not release both of the size,please understand, if you need other type of valve, please contact us!

Following is both of the detail:

Commonly used solenoid valve parameters are as follows:

1, normally closed type (i.e., electricity water)

2, the inlet valve (work pressure, 0.02-0.8 MPa, generally is connected to the pipe or booster pump, pressure from congress party use!) Drain valve (work pressure, 0-0.02 MPa is often used for bottled water switch water!)

3, the installation Angle: parallel (180 degrees)

4, method of interface:Out diameter10-12 mm!

5, voltage: DC12V DC24V, AC220! If you need to order pls remark the voltage or we will sent 220V as no require!!

Normally closed water electromagnetic valve:

This product performance is stable, durable, safe and reliable, high sensitivity, quality assurance, good appearance.

The main technical parameters:

1, the use of environmental height less than 2500 meters above sea level; The atmospheric pressure of 86 ~ 106 kpa;

2, The environment temperature + 1 °C ~ + 45 °C; Water temperature 0 °C ~ + 100 °C; Storage and transport of temperature - 30 °C~ + 60 °C;

3, protection grade IP00; Relative humidity of 95% or less

4, working parameters:

(1) the rated working voltage: dc AC220V DC12V DC24V, communication and other (15%), production line detection using voltage down; Power rating: 4 w, 5 w, etc.;

(2) working current:

(3) Working pressure (9.5 mm) open valve diameter for Φ: 4 w is 0 ~ 350 mm water column of 0 ~ 400 mm water column, 5 w, 6 w of 0 ~ 500 mm water column.

(4) working life: adopt import stainless steel spring and high quality material, the normal work of not less than 200000 times (calculate by work 100 times a day, more than five years of life);

5.the single inlet valve diagram:

Plug wire terminal direction (refers to overlook the coil to coil center as the origin, the electromagnetic valve inlet axis and the counterclockwise relative Angle between terminals, can be used according to the customer request) : respectively 0 ° and 90 °, 180 °, 270 °;

If you need more help pls chat with us!
