Professional made industrial 12v 3000 rpm dc pump motor

Professional made industrial 12v 3000 rpm dc pump motor

FOB Price:

US 80-180 / Piece

Min.Order Quantity:

20 Piece/Pieces

Supply Ability:

50000 Piece/Pieces per Month

Port:

Shanghai port

Place of Origin:

Shanghai, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T

Brand:

Products Model:

ZYT124 ZYT142

Products Details
Company Profile

Quick Details

Brand Name: GW

Model Number: ZYT124 ZYT142

Place of Origin: Shanghai, China (Mainland)

Packaging & Delivery

Packaging Details: Packaging Details: Export standard: inner box+carton+wooden case Delivery Detail: Within 20-30 days after received the deposit
Delivery Detail: Shipped in 30 days after payment

Specifications

Product Description

Professional made industrial 12v 1800 rpm dc pump motor

Low noise, small size, light weight
High output power, high efficiency
Mechanical properties of hard, stable electromagnetic properties.

Hot Products Pictures

Industrial permanent magnet DC motor drive motor is general industrial products, widely used in aerospace, aviation, transportation, energy, metallurgy, machinery, chemical industry, light industry, textile, medical equipment, fitness equipment, electric welding machine and all kinds of instruments, etc..

Motor Technical Data

Moder	Power (HP)	Voltage (V)	Current (A)	RPM	Torque (N.M)	Ins. class	Frame	Encl.	Duty
ZYT124-01	1/4	90	2.5	1750	1.01	F	SS56C	TEFC	CONT
ZYT124-03	1/3	90	3.5	1750	1.36	F	SS56C	TEFC	CONT
ZYT124-05	1/2	90	5	1750	2.03	F	SS56C	TEFC	CONT
ZYT124-07	3/4	90	7.6	1750	3.05	F	SS56C	TEFC	CONT
ZYT142-19	1	90	10	1750	4.07	F	SS56C	TEFC	CONT
ZYT142-21	1.5	180	7.6	1750	6.1	F	S56C	TEFC	CONT
ZYT142-01	1/4	12	21	1800	0.99	F	S56C	TENV	CONT
ZYT142-04	1/2	12	39	1800	1.98	H	S56C	TENV	CONT
ZYT142-08	3/4	24	29	1800	2.97	F	S56C	TEFC	CONT
ZYT142-06	1.5	48	27	1800	5.93	H	S56CZ	TENV	2min

ManufacturingProcess

GW Industry is a leading motor manufacturer which was formally known as Shanghai Micro Motor Factory (established in 1952) and joint venture with Regal-Beloit from 2002 to 2014. The JV manufactured motors for Regal Beloit under the Leeson, Marathon, and Lincoln brands.After dissolution in 2014, this entity has become part of GW Industrial Group.

Our company produces and sells a variety of NEMA/IEC design motors including single-phase / three-phase AC asynchronous motors, brush/brushless DC motors under brand “GW”, “AG-I”, and “SMC”. Over 70% of our products are sold to US, Canada, and European markets, serving industrial applications such as Fan-Blower, Agricultural Equipment, Wash-Down Equipment, Pump, Hydraulic Machinery, Transmission Apparatus, etc.

To satisfy customer’s needs, our products are certified by UL, CSA, CE, and CCC; and all materials in our products comply with RoHS requirements. Our lab has been certified by UL and CSA since 2007, being capable of performing UL/CSA certification test on site.

Basic Information

Business Type: Manufacturer
Main Products: Design and production of electric motors and related components, sales of products, services and customer service to provide technical advisory services, engaged in goods and technology import and export business.
Location: Shanghai, China (Mainland) Asia
Year Established:

Trade Capacity

Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES
Accepted Payment Currency: USD,EUR,CNY
Accepted Payment Type: L/C,T/T,Credit Card,PayPal,Cash
Nearest Port: Shanghai
