Brand Name: Yuanda Boiler
Model Number: DZH
Place of Origin: Henan, China (Mainland)
Wood fired steam boiler
Features
1.Single cylinder,fire tube(Spirally corrugated tube) and water tube.
2.Packaged style
3.Fuel can be wood pellet,peanut shell palm shell,coconut shelland other biomass fuel.
4.Hand fired type.
5.Capacity 1Ton-6Ton/HR
5.Equipped with full set auxiliaries,after simple installation,the boiler can operate
Technical Data
Model |
DZH1-0.7-AII |
DZH2-1.0-AII |
DZH4-1.25-AII |
DZH6-1.25-AII |
Rated evaporation( t/h) |
1 |
2 |
4 |
6 |
Rated steam pressure( Mpa) |
1.0 |
1.0 |
1.25 |
1.25 |
Feed water temp(°C ) |
20 |
20 |
20 |
20 |
Rated steam temp(°C ) |
184 |
184 |
194 |
194 |
active grate area( M2) |
1.85 |
3.4 |
5.18 |
7.55 |
Applicable coal style |
AII |
AII |
AII |
AII |
flue gas temperature(°C ) |
157.3 |
163.1 |
180 |
166.3 |
Designed thermal efficiency(%) |
80.33 |
80.54 |
80.28 |
80.94 |
Coal consumption (Kg/h ) |
118 |
238 |
472 |
685 |
Transportation Weight(t) |
13.2 |
13.8 |
23 |
32 |
