Commercial Glass Door Freezer Supermarket Island Freezer

Name

  electric heated glass door for supermarket refrigerator freezer wine

Temperature range

-25°C~0°C

Hollow Glass

Yes

Electrical Heating

Yes

Per door Dimension

1700mm*650mm*37mm,663mm*763mm*37mm, or customized

Voltage

220V/50Hz, OR adjust the voltage to your country standard

Door QTY

as your request

Thickness

4mm+6A+9A+3mm,3mm+6A+9A+3mm,4mm+6A+3mm+15A+3mm OR customized

Specification

1. Tempered Low-e Insulating glass

2. Outer Framed

3. Silver bar

4. Door gasket with magnet

5. Safe handle

6. Door spindle

7. Self-closing systems

8. With heated safety glass and heated frame

9. 90° hold-open feature

10. Electrode and Heating wire

Frame

1. Eco-friendly PVC alloy and ABS

2. Aluminum alloy

3. Customized

Handle

Aluminum or Customized

Color

Silver, golden OR customized

Service

ODM/OEM/customer's designs are available

Application

home refrigerator, commercial refrigeration cabinets, supermarket refrigerator

Type of glass

Tempered white glass, tempered Low-e glass

Hollow glass layer

Single, double, triple OR customized

Advantages
of our doors

1. Reduction of electricity consumption.

2. Optical performance, Clear view of the goods on the shelf.

3.Anti-fog,Anti-condensation,Anti-frost

4. Thermal insulation, Constant cooling temperature keeping products fresh.

5. Eco-friendly, Reduction in Carbon footprint.

6. Easy handling and access for customers and staff.

7.90° hold-open feature for easy loading

8.Safety glass door

9.used of polysulfide rubber to seal, door gasket with magne

Feature

• Ice melting function: power off, glass temperature reach to 35 to 40°C, over air dew point.
• Good optical performance: electric heated glass adopts static wire and film as the heating medium, ensure the good transmittance. The driver can see clearly through the glass.
• UV protection and radiation protection: electric heated glass has hight ability to absorb the ultraviolet rays, which can protect indoor from ultraviolet rays.
