12v electric valve for Irrigation equipment, drinking water equipment, solar water heaters

12v electric valve for Irrigation equipment, drinking water equipment, solar water heaters

12V  Electric valve

Motorized ball valve features: excellent capacity of water stoppage, large water flow rate, zero dirt block, low torque, nice design and easy installation.

 Parameter

1.two way motorized ball valve electric water valve

2.Size:  DN50-DN100

3.Voltage:DC12-24V  AC220V50HZ

4.Pressure:16bar

5.Metal gear

6.Service life: 100000 times

7.Rated Current: 500mA

8.Protection : IP65

9.Output Torque: 100NM

10.Open/close time:18-25sec

11.Actuator rotation:90 degree

12.Body: UPVC  Cast steel  cast iron   stainless steel

13.Electric with manual

Products Features:
1, smart shape, perform reliably, brass gear, PPO parts, large output  torque, long product life.
2, Electrical limit and machinery limit design, accurate position.
3, Multi - assembling, easy to install.
4, Float ball structure, no leakage, especially suitable for heavy  pollution conditions.
5, good substitution for solenoid valve.
6, High protection class, can be worked in moist conditions. IP65
Suitable for
1, IC card meters, heat energy meters, air-warm valve.
2, Heating, Ventilation and Air Conditioning and fire work.
3, Water equipment, uto-control water system, industrial mini-auto equipment .
4, Irrigation equipment, drinking water equipment, solar water heaters,  washing machins, water heaters, industrial .

mini motorized valve,actuated valve,automatic valve,control valve,motor operated valve,motor actuated valve,hydraulic valve.

Motorized ball valve features: excellent capacity of water stoppage, large water flow rate, zero dirt block, low torque, nice design and easy installation.

Key words:

mini electric ball valve for water treatment,HAVC,automatic control,for watermeter motorised ball valve,for watertreatment,for IC card meters,for air-warm valve HVAC motorised ball valve,Mini dimension suits for small equipment/HVAC Water treatment Small equipment for automatic, control,Replacing solenoid valve, particularly when solenoid cannot work reliably,mini motorised valve, actuated valve, motor operated valve, motor actuated valve, automatic valve, control valve, shut off valve, hydraulic valve, electric valve, electronic valve.electric valve for water automatic control,brass or stainless steelmini motorized valve, actuated valve, motor operated valve, motor actuated valve, automatic valve, control valve,shut off valve, actuator valve, electric operated valve
