AC120V DN40 Electric Valve With Actuator for solar thermal,under-floor,rain water,irrigation,plumbing service

Detailed Product Description

electric solenoid water valve

1.two way motorized ball valve electric water valve

2.Size:  DN50-DN100

3.Voltage:DC12-24V  AC220V50HZ

4.Pressure:16bar

5.Metal gear

6.Service life: 100000 times

7.Rated Current: 500mA

8.Protection : IP65

9.Output Torque: 100NM

10.Open/close time:18-25sec

11.Actuator rotation:90 degree

12.Body: UPVC  Cast steel  cast iron   stainless steel

13.Electric with manual

Products Features:
1, smart shape, perform reliably, brass gear, PPO parts, large output  torque, long product life.
2, Electrical limit and machinery limit design, accurate position.
3, Multi - assembling, easy to install.
4, Float ball structure, no leakage, especially suitable for heavy  pollution conditions.
5, good substitution for solenoid valve.
6, High protection class, can be worked in moist conditions. IP65
 Suitable for
1, IC card meters, heat energy meters, air-warm valve.
2, Heating, Ventilation and Air Conditioning and fire work.
3, Water equipment, uto-control water system, industrial mini-auto equipment .
4, Irrigation equipment, drinking water equipment, solar water heaters,  washing machins, water heaters, industrial .

mini motorized valve,actuated valve,automatic valve,control valve,motor operated valve,motor actuated valve,hydraulic valve.
