Home > Products > Intelligent Control > Actuator

Underfloor Heating 230V Thermo Actuator

FOB Price:

US 5.5-10.5 / Piece

Min.Order Quantity:

1000 Piece/Pieces

Supply Ability:

20000 Piece/Pieces per Month

Port:

ningbo or shanghai

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T

Brand:

BENTAI

Products Model:

DR SYSTEM

Products Details
Company Profile

Quick Details

Brand Name: BENTAI

Model Number: DR SYSTEM

Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

Packaging Details: Selling Units: Single item Single package size: 40X28X23 cm Single gross weight: 15.0 KG Package Type: white inner box + common brown box
Delivery Detail: 25days

Specifications

Underfloor Heating 230V Thermo Actuator

Specifications:

1.NO/NC
2.12VDC/24VDC/110VAC/230VAC
3.Power:2W
4.Stroke:3mm-5mm

Detailed description:

Certificate: EN215 ,CE ,ISO9001:2008, IAF

Material: Brass

Size:DN15/DN20/DN25

Angle/Straight Valve

Voltage: DC12V,DC24V,AC110V,AC230V(220V)

Power Consumption: 2W

Function:N0/NC

Stroke: 3mm-5mm

Thrust:110N

IP54

Starting Time: 3-5min

Join Size: M30*1.5mm

Environment Temperature :From -5C°to 60°C

Wire Length: 1000mm

2.Thermostatic valve body

Made of brass, easy to be installed

Low resistance

Water temperature : less than 120 degree

Normal resistance to pressure: 10 bar
