Tungsten copper alloy W80Cu20 W75Cu25 W70Cu30 ASTM B702

Tungsten copper alloy W80Cu20 W75Cu25 W70Cu30 ASTM B702

FOB Price:

US 80-480 / Kilogram

Min.Order Quantity:

1 Kilogram/Kilograms

Supply Ability:

10 Ton/Tons per Month

Port:

Shenzhen,Shanghai,Tianjin,Qingdao

Place of Origin:

Shaanxi, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal

Brand:

Hanztech

Products Model:

W1 W2

Products Details
Company Profile

Quick Details

Brand Name: Hanztech

Model Number: W1 W2

Place of Origin: Shaanxi, China (Mainland)

Packaging & Delivery

Packaging Details: Standard export package or on the clients' requirement, Plastic bags and kraft paper as inside, wooden case as outside, about Tungsten copper alloy W80Cu20 W75Cu25 W70Cu30 ASTM B702.
Delivery Detail: 3-15 workdays

Specifications

Product Description

Item	Tungsten copper alloy W80Cu20 W75Cu25 W70Cu30 ASTM B702
Normal size	Thickness: min: 0.10mm max: >6.0mm Width:<400mm Length: <1000mm
Special size	Thickness:0.02-1mm Width: Discussion Length: Discussion
Surface	Hot rolling , cold rolling, alkaline cleaning , machining, polished, grinding
Stock	0.085mm, 0.1mm, 0.2mm, 0.5mm,1.0mm,1.5mm,2.0mm and so on
shape	foil,sheet,plate, disk, block, round disc
Application	industrial, medical, metallurgical, electric vacuum components, electric light source parts, heat shield, aerospace development

AMST 21014 class 1	AMST 21014 class 2
1. 90%WNiFe, 90%WNiCu 2. Density : 16.85-17.30 g/cm3 3. Hardness: 32HRC max 4. Elongation: 5 - 20% 5. Tensile Strength: 1470Mpa max 6.Impact Toughness:58J/cm2 max	1. 92.5%WNiFe, 92.5%WNiCu 2. Density : 17.15-17.85 g/cm3 3. Hardness: 33HRC max 4. Elongation: 5 - 15% 5. Tensile Strength:1720Mpa max 6.Impact Toughness:54J/cm2 max
AMST 21014 class 3	AMST 21014 class 4
1. 95%WNiFe, 95%WNiCu 2. Density : 17.75-18.35 g/cm3 3. Hardness: 34HRC max 4. Elongation: 3 - 10% 5. Tensile Strength:971Mpa max 6.Impact Toughness:43J/cm2 max	1. 97.5%WNiFe,97.5%WNiCu 2. Density : 18.25-18.85 g/cm3 3. Hardness: 35HRC max 4. Elongation: 1 - 8% 5. Tensile Strength:964Mpa max 6.Impact Toughness:22J/cm2 max

Chemical Composition:

Code No.	Chemical Composition %			Mechanical properties
Code No.	CU	Impurity	W	Density (g/cm3 )	Hardness HB	RES( cm)	Conductivity IACS/ %	TRS/ Mpa
CuW50	50+/-2.0	0.5	Balance	11.85	115	3.2	54
CuW55	45+/-2.0	0.5	Balance	12.30	125	3.5	49
CuW60	40+/-2.0	0.5	Balance	12.75	140	3.7	47
CuW65	35+/-2.0	0.5	Balance	13.30	155	3.9	44
CuW70	30+/-2.0	0.5	Balance	13.80	175	4.1	42	790
CuW75	25+/-2.0	0.5	Balance	14.50	195	4.5	38	885
CuW80	20+/-2.0	0.5	Balance	15.15	220	5.0	34	980
CuW85	15+/-2.0	0.5	Balance	15.90	240	5.7	30	1080
CuW90	10+/-2.0	0.5	Balance	16.75	260	6.5	27	1160
