Shape memory nickel titanium alloy wire

 Shape memory nickel titanium alloy wire

Product  Show

 o Manufacturing 0.2mm nickel titanium wire with high quality

Quick details

1..Size:  Shape memory nickel titanium alloy wire

Wire:Dia0.05-6.0mm

Bar:Dia3.0mm—20mm

Sheet: Thickness 0.3-10.0mm  Width≤400mm  Length≤2500mm

2.Surface State Options:  Shape memory nickel titanium alloy wire

  ♣   Black oxide surface

  ♣ As cleaned surface
  ♣  Medical grade polished surface
  ♣  Centerless ground surface

 3. Chemical composition:

Ni: 55.4% --56.2% C≤0.07 H≤0.005 O≤0.050 N:≤ 0.05

 4.Applicationo Shape memory nickel titanium alloy wire

cell phone antenna, children's toys, experimental materials, glasses leg, women bra,                    Women's Sports Central,arch wires, instruments, and medical equipment, such as surgical stitching wire,

 birth control loop and other areas of high-quality memory alloy wire.

  ASTM F2063 polished nitinol dental implant wire

5.Standard: A Shape memory nickel titanium alloy wire

 ASTM F2063-05  Q/XB1516  Customer specified or Industry Standard

 How does nitinol work?

      Nitinol Shape Memory Alloys undergo a phase transformation in their crystal structure when cooled from the stronger, high temperature from (Austenite) to the weaker, low temperature from (Martensite). This inherent phase transformation is the basis for the unique properties of these alloys - in particular, Shape Memory and Superelasticity.

Shape Memory of  superelastic nitinol wire 1.5mm

     When shape memory alloys are in their martensitic form, they are easily deformed to a new shape. However, when the alloy is heated through its transformation temperatures, it reverts to austenite and recovers its previous shape with great force. This process is knows as Shape Memory.

     The temperature at which the alloy remembers its high temperature from when heated can be adjusted by slight changes in alloy composition and through heat treatment. In the Nickel Titanium alloys, for instance, it can be changed from above +100 deg. C to below -100 deg. C. The shape recovery process occurs over a range of just a few degrees and the start or finish of the transformation can be controlled to within a degree or two if necessary.

Superelasticity o Shape memory nickel titanium alloy wire

     These unique shape memory alloys also show a Superelastic behavior if deformed at a temperature which is slightly above their transformation temperatures. This effect is caused by the stress-induced formation of some martensite above its normal temperature. Because it has been formed above its normal temperature, the martensite reverts immediately to undeformed austenite as soon as the stress is removed. This process provides a very springy, "rubberlike" elasticity in these alloys.

Packaging and Shipping

Packaging o Shape memory nickel titanium alloy wire

• Carton with water proof paper and protective foam inside

  • Standard wooden case

  • As cilents' requirements

Titanium nickle Nitinol alloy Wire with best price

TNT, EMS, UPS, FED, DHL, Air transport, Sea Transport, Railway Transport are available.

Depends on your demands, we will try our best to choose the most suitable way for you.

 After we send the product, we will send the track number to you with Email, and also we will track

this order until you can received successfully.

 Company Information

 Baoji Hanz Material Technology Co., Ltd located in Baoji,China.With high preciously equipment and rich experience, our company specilizes in manufacturing  all  shapes of nitinol alloy products.      Made
