China Grade A boiler supplier steam boiler components pendant superheater

China Grade A boiler supplier steam boiler components pendant superheater

Specification:

Super heaters are the one of the most important boiler sapre parts that improves the thermal efficiency. High temperature steam boiler radiant super heater is usually applied in high pressure power plant boiler.

In the boiler, the role of super heater is to heat the saturated steam to a certain temperature of superheated steam to increase power plant efficiency. Repeater essentially further improves the thermal power plant cycle efficiency.

 Steam Super heater Coils: Super heater coils are used in a boiler to generate saturated steam. The super heater coils are specially used in Boilers of Power plant. We manufacture Super heater coils in various grades of Alloy steel and in stain less steel tubes with or without support & Header as per customer’s drawing.

Thechnical parameters:

Description:

Super heater types:

1. Radiant super heater: it is the earliest type of super heater and it is located above or behind banks of water tubes to protection them from direct flam or fire.

Parameters that increases the convection

a. Increasing the fuel-and air flow (combustion gas flow)

b. Increasing the mass flow rate of the steam

 Radiation is mainly dependent on the flam temperature. as the steam flow rate increases the exit temperature become lower.

Radiant super heater

They are placed exposed to the heat source whcih requires the improvement of metal temperatures.

Radiant and convetive super heaters and reheaters are used for high temperature steam.

The accessory of  high temperature radiant steam  super heater in boiler

It is made up of snake-like tubes (carbon steel, alloy steel or heat-resistant steel, etc.) and collection boxes and other supporting material. Tubes generally have φ32, φ38, φ42 or other types of specifications, according to user's needs separately.

Reheaters

They are the sane as the super heaters but as their exit temperature is a little bit less than super heaters and their pressure is 20% -25% less than the super heater, they can stand less quality material alloys.

Application:

Steam super heater is consisted of dense tube coils and is placed in the flue under the tempearture 450℃-1000℃.

For power plant boiler capacity over 10Mpa, platen and coiled superheater are usually adopted.

Other hot products

Our company:

Shandong Hengtao Group, founded in 1995, is located in Gaomi City, Shandong Province. Hengtao Group has 470,000,000 RMB of total registered capital, 1,400,000 square meter of land coverage, about 2000 employees and over 3 billion RMB of total assets.

We are one of the manufacturers of boiler and boiler parts in China. We have a team of engineers who have more than 20 years experience in designing, manufacturing, engineering, supplying of boiler and its spare parts. We manufacture CFB boiler, enameled corrugated plate, enameled tubular air preheater, rotary air preheater, H-finned tube economizer, spiral finned tube economizer, membrane water wall, header and other customized boiler parts.

Workshop& packing & shipment:

Clients:

Certification

1. ISO 9001 certificate

2. ISO 14001 certificate

3. ASME standard

4. TUV & BV certified applier
