ZRF Series Flange Oil Separator

FOB Price:

USD 20-50 / Piece

Min.Order Quantity:

50 Piece

Supply Ability:

10000 Piece per Month

Port:

Ningbo/Shanghai

Place of Origin:

China

Payment Terms:

L/C, T/T, Western Union

Brand:

ZOER

Products Model:

ZRF

Products Details
Company Profile

Quick Details

Brand Name: ZOER

Model Number: ZRF

Place of Origin: China

Packaging & Delivery

Packaging Details: Export neutral standard packing/According to client requirement.
Delivery Detail: 15-25 days from the date of receiving deposit

Specifications

Product Introduction:

When compressor is in operation, the outlet of compressor always has lots of refrigerant oil, so in order to prevent compressor not loss too much refrigerants and prevent the oil flow to system with refrigerants to interfere condenser's heat function and evaporator's cooling function, we need to install an oil separator between compressor and condenser to separate refrigerant oil and refrigerants.

Then the oil will flow back to the compressor crankcase, the oil return device operated by the ball valve on the bottom of separator and uses high-low pressure theory. The oil separator can ensure the sufficiency of oil in compressor and let it reach best cooling performance.

Features:

1. Steel oil return system with hermetic welded construction (1/4” or 3/8” SAE connectors);

2. Reliable needle valve closing system;

3.The interaction of flow speed reducing and flow direction changing making the oil gathering, thus the lubricants separated under high temperature will be collected and automatically return to the compressor crankcase;

4. Suction corrosion resistant static electrical painting procedure protecting the shell from the rust;

5. Reduce the vibration and noise at the high pressure end of system;

6. Maximum working pressure: 3.5Mpa.

Design Functions:

1. ODF Connection (TP2Y2);

2. End cap (ST12);

3. Filter mess (0Cr18Ni9Ti);

4. Holding Plate (08F);

5. Oil concentrator (Q235);

6. Steel shell (Q235);

7. Floating ball (ST12);

8. Needle Valve (20#)

Specification:

Type	Connection size (ODF)	Demensions(mm)		Corresponding type
Type	Connection size (ODF)	A	B	Corresponding type
ZRF-4004	1/2	102	290	ZRF-5302
ZRF-4005	5/8	102	350	ZRF-5303
ZRF-4007	7/8	102	385	ZRF-5304
ZRF-4011	1-1/8	102	413	ZRF-5305
ZRF-4013	1-3/8	102	498	ZRF-5306
ZRF-4015	1-5/8	102	498	ZRF-5307
ZRF-6011	1-1/8	159	430	ZRF-6302
ZRF-6013	1-3/8	159	430	ZRF-6303
ZRF-6015	1-5/8	159	430	ZRF-6304
ZRF-6021	2-1/8	159	430	ZRF-6305

ZRC _conew1.jpg

Company profile
ZhuoEr was founded in 2015, comes from a factory with 10 years' professional experience of refrigeration components manufacture(original company name:Xinchang Zhuoer Refrigeration Co.,Ltd),specialized in manufacture refrigeration products, and organized to expand production, and get self-management of export for our perfect components to the whole world.

Development
ZhuoEr has developed as a group owning professional skilled technology and solid enterprise cohesive force, top quality and customer satisfaction at the first level is our target. We commit ourselves to continuous absorption of advanced technology and superior management from domestic and international markets, and introduced advanced equipments, such as highly automatic CO2 Brazing Machine, Automatic Molecular Staffing Machine and Electrical Pressure Testing Equipments, etc.

ZhuoEr uphold mature and scientific management, such as 6S field management system, making production according to European quality requests and safety regulations successfully, approved & registered ISO9001: 2008 Certification and PED Certificate.
Our components have a well market-share in both domestic and international markets, and exported to worldwide, mainly in Europe, India, Saudi Arabia, America, Asia and everywhere in the world.

Products
Our components including Filter Drier, Suction Line Accumulator, Oil Separator, Oil Receiver, Filter drier Core Shell, Liquid Receiver, Nuts & Adapters, all are compatible with all available new eco friendly refrigerants,

All components are developed and manufactured inside the factory itself. The wide range of standard components can be found in our catalogue is further enriched by the special components which ZhuoEr R&D designs according to the customer's specific needs, and OEM is available.
