Brand Name: BLUE
Model Number: BLR/
Place of Origin: ZHEJINAG
BLR/TPH Pressure Hose&Fitting
BLR/TPH Pressure Hose & Fitting are widely uesd in aviation,aerospace,transportation facility,fork truck,engineering machinery ,auto,stage lift ,air,painting and other mechanical fields.
Specification
◆Inner Layer:Nylon Pa 12
◆Outer layer:Polyurethane(TPU)
◆Temperature:-40 to +130 ℃
◆Enhancementlayer：Polyester fiber （Industrial yarn）
◆Color available：black、blue、red、gray、orange
1.Cut the hose using proper shears,automatic or manual cutters.The cut must be perfectly square and smooth.
2.insert the sleeve on the hose with the groove towards the hose side to be assembled.
3.Push the insert inside the hose.
4.Insert the nut onto the hose
5.Make the nut slide onto the external part of the insert(flare) and push the sleeve till it covers the bottom of the free insert.
6.Assemble the hose by positioning manual pliers on the sleeve covering its whole surface.Crimp till hand pliers open automatically.A second crimping is useful to obtain a safer assembling.
|
Model
|
Color
|
Inner Dia. (mm) |
Outer Dia. (mm) |
Tolerance (mm) |
Min.Bending Radius(mm) |
Working Pressure (bar/psi) |
Weight (g/m) |
|
BLR/TPH02
|
Available on Request
|
2
|
5.9
|
0.1
|
10
|
45/653
|
30
|
|
BLR/TPH04
|
Available on Request
|
4
|
8.2
|
0.1
|
35
|
45/653
|
50
|
|
BLR/TPH06
|
Available on Request
|
6
|
10.9
|
0.1
|
35
|
45/653
|
70
|
|
Item
|
Model
|
Specification
|
|
Straight Connector
 |
BLR/TPH-S02(B)
|
For DN2 Hose,ID: 2.0MM
|
|
Elbow Connector
 |
BLR/TPH-E02(B)
|
For DN2 Hose,ID: 2.0MM
|
|
T Connector
 |
BLR/TPH-T02
|
For DN2 Hose,ID: 2.0MM
|
|
T Connector
(Middle with Nut)  |
BLR/TPH-T02M(B)
|
For DN2 Hose,ID: 2.0MM
|
|
T Connector
(Side with Nut)  |
BLR/TPH-T02R(B)
|
For DN2 Hose,ID: 2.0MM
|
|
Straight Connector
 |
BLR/TPH-S04R(B)
|
For DN4 Hose,ID: 4.0MM
|
|
Elbow Connector
 |
BLR/TPH-E04(B)
|
For DN4 Hose,ID: 4.0MM
|
|
T Connector
|
BLR/TPH-T04
|
For DN4 Hose,ID: 4.0MM
|
|
T Connector(Middle with Nut)
 |
BLR/TPH-T04M(B)
|
For DN4 Hose,ID: 4.0MM
|
|
T Connector(Side with Nut)
 |
BLR/TPH-T04R(B)
|
For DN4 Hose,ID: 4.0MM
|
|
Gasket
|
BLR/THP-02G
|
(for DN2,DN4,DN6 Hose)
|
|
Needle
|
BLR/THP-02N
|
(for DN2,DN4,DN6 Hose)
|
|
Hand Crimper
 |
BLR/MHC02A
|
(for DN2 Hose)
|
|
Manual Hand Crimper
|
BLR/MHC04A
|
(for DN4,DN6 Hose)
|
|
Manual Hand Crimper Kit
 |
BLR/HHC04CKA
|
(for DN4,DN6 Hose)
|
|
DC Electric Hand Crimper
|
BLR/HHC04B
|
(for DN4,DN6 Hose)
|
|
DC Electric Hand Crimper Set
 |
BLR/HHC04CKB
|
(for DN4,DN7 Hose)
|
|
Tube Cutter
|
BLR/TC02A
|
(for DN2,DN4,DN6 Hose)
|
|
pressure hose with fittings(two side straight) |
BLR/TPHS-60
|
Longth:60cm Connection:Straight
|
|
pressure hose with fittings (two side straight) |
BLR/TPHS-90
|
Longth:90cm Connection:Straight
|
|
pressure hose with fittings(two side straight) |
BLR/TPHS-120
|
Longth:120cm Connection:Straight
|
|
pressure hose with fittings (one straight,one elbow) |
BLR/TPHSE-60
|
Longth:60cm Connection:Elbow and Straight
|
|
pressure hose with fittings (one straight,one elbow) |
BLR/TPHSE-90
|
Longth:90cm Connection:Elbow and Straight
|
|
pressure hose with fittings (one straight,one elbow) |
BLR/TPHSE-120
|
Longth:120cm Connection:Elbow and Straight
|
|
pressure hose with fittings(two side straight) |
BLR/TPHE-60
|
Longth:60cm Connection:Elbow
|
|
pressure hose with fittings(two side straight) |
BLR/TPHE-90
|
Longth:90cm Connection:Elbow
|
|
pressure hose with fittings(two side straight) |
BLR/TPHE-120
|
Longth:120cm Connection:Elbow
|
